SMT 5.0-S
The most user-friendly automatic B1 machine
Main reasons for choose a TAULER SMT5.0-S:
- Because it incorporates the TAULER_OIL system, which improves rolling and reduces energy consumption.
- Because it features a quick-adjustment function for the bobbin whilst the machine is running.
- Because it features the TAULER_SHAFT SYSTEM, which makes it easy to change the spool quickly.
- Because the TAULER_FOIL system allows you to produce toner prints.
- Thanks to its intuitive touchscreen.
- Because it features a REVERSE MODE to correct any errors.
- Because it features TAULER_GO ON, an automatic start-up system.
- Because it has a stacking system that allows for palletised unloading.
Technical details:
- Automatic feeding with front suction and two suction cups.
- Adjustable side support.
- Temperature control by sensor.
- Pneumatic pressure roller.
- Easily adjustable unrolling system.
- A photocell that stops the machine in the event of a blade failure.
- Total control of the machine through a PLC.
- Electronically adjustable speed.
- Micro-perforation and scissor roller cutting system.
Maximum length [A]: 376 cm
Maximum width [B]: 173 cm
Maximum height [C]: 150 cm
Weight: 1.500 Kg
Fill in the form below and get our catalogue.
"*" indicates required fields
Technical specifications
| Maximum format | 760 x 1060 mm |
| Minimum format | 220 x 250 mm |
| Maximum mechanical speed | 2 – 25 m/min* |
| Paper thickness | 120 a 600 g/m2 |
| Height of the inlet/outlet stack | 650 mm |
| Gruix del plàstic | 20 to 50 μm |
| Installed electrical power | 10 kW |
| Alimentació | 380 V trifàsica 50 Hz |
| Security | Protective guards, emergency stop devices and safety sensors compliant with CE standards. |
*Depending on the film, external conditions, paper type, thickness and formats.
TAULER reserves the right to modify the characteristics of this product without prior notice. The image shown and the information reflected in this website & brochure does not establish contractual information. TAULER AND PRINTLAM ARE TRADEMARKS OF TAULER LAMINATING TECH, S.L.
