GFM1080
Automatic hot knife sheeter
Characteristics:
- Automatic non-stop paper loading.
- Fully cast body lamination unit.
- Multi-servo transmission, improves precision and efficiency.
- Ceramic anilox rollers for automatic glue adjustment.
- Hot knife servo motor with automatic edge correction structure, glue film free cutting.
Max. length [A]: 13.96 m (40 ft)
Maximum width [B]: 3,24 m
Maximum height [C]: 3,8 m
Weight: 11.800 kg
Fill in the form below and get our catalogue.
"*" indicates required fields
Technical data
| Model | GFM1080 CRQ |
| Maximum format | 1080 x 800 mm |
| Minimum format | 500x 350 mm |
| Maximum mechanical speed | 100 m/min* |
| Paper thickness | 80 a 500 g/m2 |
| Stack height | 1500 mm |
| Installed electrical power | 99 kW |
*Depending on the film, external conditions, paper type, thickness and formats.
TAULER reserves the right to modify the characteristics of this product without prior notice. The image shown and the information reflected in this website & brochure does not establish contractual information. TAULER AND PRINTLAM ARE TRADEMARKS OF TAULER LAMINATING TECH, S.L.
